Sewer Jetting Machine Trailer

Our Product Category
Brochures

Sewer Jetting Machine Trailer


This product is capable of De-Chocking and De-Silting civic, Industrial drains and sewer lines by using the principle of hydrodynamic cleaning by injecting high pressure water into the lines through a suitably dimensioned sewer jetting hose and special cleaning nozzles

TECHNICAL SPECIFICATIONS
Recommended Chassis Required GVW as per Capacity & Payload cabin chassis with PTO & In Case of Trailer then required suitable Tractor with PTO Provision
High Pressure Jetting Pump Imported Make Only Discharge Capacity – 100 LPM @ 150 Bar to 250 LPM @ 170 Bar The High Pressure Jetting Pump Will Be Driven by Split Shaft Total Power Take Off Unit Suitable for Cleaning Drain Lines of Diameters Ranging from 100mm to 400mm Type- Triplex Plunger Pump Suction filter, Unloaded Valves & safety valve provided to protect the high pressure jetting system
Accessories & Safety Devices Pressure Relief Valve, Safety valves, Unidirectional Valve, Primary Shut Off, Secondary Shut-Off, Direction Control And Flow Control Valves, Stainless Steel Filters, Online Pilot Operated Check Valves Etc.
Jetting Hose & Hose Reel Type- Pivoted Type Rotation- 90°, A Single Length,60 Meters Long with 3/4” Of internal Dia., High Pressure Thermo-Plastic (Jetting) Hose Working Pressure 130 Bar, Bursting Pressure: 400 Bar Construction of Core: Thermoplastic Techno Polymer Core with Two Braided High Tensile Fiber Pressure Reinforcement. Outer Cover Made Of Thermoplastic Synthetic Techno Polymer, A kit of two cleaning nozzles, (a) Round - head - nozzle (b) Conical - head - nozzle, capable of removing heavy chokes should also be supplied with the equipment
Pump Drive Drive for The Jetting Pump Will Be from A New Generation Total Power Take Off Unit, Split shaft PTO, The P.T.O. Will Be Capable Of Transmitting The Full Engine Torque Of The Vehicle
Painting / Finishing Of The Complete Equipment Both, Exterior and Interior of the Tank Will Be Sand Blasted Prior to Spray Painting. The Tank Exterior Shall Be Spray Painted with Two Coats of Superior Quality Anti-Corrosive Primer and Two Coats of Enamel Metal Paint of Reputed Make. The Tank Interior Will Be Coated with 2 Coats of Anti-Corrosive primer & Grey Epoxy Paint The Whole Equipment With Cabin Shall Be Painted With Two Coats Of Enamel Paint In Golden Yellow Color.
